STANDARD MOUNT:


The Standard Mount is ideal for direct pick-up replacement in the professional Gretsch lines of guitars and basses. A mounting ring is necessary to hide the longer pick-up cavity.

  Best suited for the following Guitars:


Gretsch Tennessee Rose
Gretsch 6120
Gretsch Setzer HotRod
Gretsch Country Gentleman
Gretsch Jet Firebird

 Gretsch Malcolm Young
Gretsch White Falcon
Gretsch Black Falcon
Gretsch Country Club
Gretsch White Penguin






























STANDARD MOUNT  NO EARS:
The Standard No Ears mount is a great choice when a clean rout is desired. It allows for a nice tight fit when a pick-up ring is not used - similar to a P90 soapbar pick-up.
The No Ears with short screws is ideal for direct replacement in a Fender-style solid body guitar or bass.

Best suited for the following Guitars:
Gretsch Tennessee Rose
Gretsch 6120
Gretsch Setzer HotRod
Gretsch Country Gentleman
Gretsch Jet Firebird
Gretsch Malcolm Young
Gretsch White Falcon
Gretsch Black Falcon
Gretsch Country Club
Gretsch White Penguin

Fender Tele
Fender La Cabranita
Gretsch Pro Jet
TV Jones Spectra Sonic Supreme (se bild).




The standard No Ears mounting option is best for clean routes using no ring.




















ENGLISH MOUNT
The English Mount allows you to swap out your stock humbuckers with a TV Jones Filter'Tron™ style pickup (pictured top and bottom view to show how the feet suspend the pickup). This mounting option when coupled with a Gretsch pickup ring is the perfect choice for a 5120 style Gretsch guitar. For Les Paul or Ibanez Artcore the Gibson-style ring would go on the English Mount. For Dogear pickups we offer the Dogear ring. Stock Gibson or Gretsch rings will not fit. You must purchase the TV Jones rings to work with the English Mount. All English Mounts are designed for open pickup cavities with no support.

Please Note: This mounting option is NOT intended for Professional Collection Gretsch® guitars (eg; 6120, White Falcon, Jet series, Country Gentleman®, etc.)








Best suited for the following Guitars:
with Gibson-Ring (EM1) with DogEar-Ring (EM3) with Gretsch-Ring (EM2)
Gibson Les Paul
Gibson Flying V
Gibson Explorer
Gibson ES-335
Epiphone SG
Epiphone Les Paul Custom
Ibanez Artcore AFS 75-T
Heritage 535
Hagstrom HJ-500
Hamer Monaco, Newport 		Epiphone Wild Kat
Epiphone Casino 		Gretsch Electromatic Hollowbody 5120, 5122
Gretsch Electromatic Elliot Easton 1570
Double Jet 5245, 5246, 5248
















DeARMOND MOUNT
The DeArmond mount is for guitars with top-mounted DeArmond® or Dynasonic® single-coil pickups. Now you can have that classic TV Jones double-coil sound without modifying your guitar! Now available in chrome nickel and gold covers.


Best suited for the following Guitars:
Gretsch 6120 with DynaSonic Pick-ups
Gretsch Silver Jet/Sparkle Jet with DynaSonic Pick-ups
Gretsch White Falcon 6136 DS
Gretsch Electromatic Hollowbody 5125, 5126, 5128, 5129
Gretsch Junior Jet 5210, 5215

















SOAPBAR MOUNT
The Soapbar Mount uses the same size cover as a stock P-90 soapbar but with a TV Classic pickup under the hood.
Retro-fits in any guitar equipped with soapbars. Available in black and cream




Best suited for the following Guitars:
Gibson Les Paul Gold Top
Epiphone Les Paul 1956 Gold Top
Gibson ES-135

















HUMBUCKER MOUNT

The Humbucker Mount (formerly TV'Tron) uses the same size cover and baseplate as a standard humbucker, so it can be mounted into any guitar with standard humbucker pickup cavities. Since the pickup cover is completely enclosed, we use nickel/silver alloy instead of brass to retain as much clarity as possible.


Best suited for the following Guitars:
Gibson Les Paul
Gibson Flying V
Gibson Explorer
Gibson ES-335
 		Epiphone SG
Epiphone Les Paul Custom
Epiphone Sheraton
Epiphone Casino
Ibanez Artcore
